CPU
|
AMD Socket A Processors DURON
AMD Athlon XP/ Thoroughbred
|
|
Chipset
|
VIA KM266A
VIA VT8235
|
|
Front Side Bus
|
200/266 MHz
|
|
Memory
|
2 x DIMM, Max. 2 GB, DDR SDRAM ,Non-ECC, Memory
|
|
VGA
|
Integrated VIA UniChrome Graphics
|
|
Expansion Slots
|
3 x PCI
1 x AGP 8x /4x
|
|
Storage
|
2 xUltraDMA 133/100/66/
|
|
Audio
|
ADI SoundMax 6 -Channel CODEC
|
|
LAN
|
VIA VT6103 100/10 Mbps Ethernet PHY
|
|
USB
|
6 USB 2.0 ports
|
|
Special Features
|
ASUS EZ Flash
ASUS CrashFree BIOS
ASUS C.P.R.(CPU Parameter Recall)
Power Loss Restart
Support S/PDIF out interface
|
|
Back Panel I/O Ports
|
1 x Parallel
1 x VGA
1 x Audio I/O
1 x PS/2 Keyboard
1 x PS/2 Mouse
1 x Serial port
1 x LAN(RJ45) port
4 x USB 2.0/1.1
|
|
Internal I/O Connectors
|
1 x USB connectors support additional 2 USB 2.0 ports
1 x IDE connector
1 x CPU Fan connector
1 x Chassis Fan connector
IDE LED connector
1 x S/PDIF Out connector
20 -pin ATX Power connector
Front panel audio connector
COM connector
Game/MIDI port connector
Power LED connetor
Chassis Intrusion connector
CD/AUX audio in
|
|
BIOS
|
2 Mb Flash ROM
DMI 2.0
PnP
WfM 2.0
SM BIOS 2.3
Award BIOS
TCAV
ASUS EZ Flash
ASUS CrashFree BIOS
|
.
