CPU |
|
Socket 478 for Intel Pentium 4, HT & Prescott processor |
|
|
|
FSB |
|
800/533/400 MHz |
|
|
|
Chipset |
|
VIA P4M800 CE/ VT8237R |
|
|
|
VGA |
|
Embedded UniChrome Pro Graphics with 64M share memory |
|
|
|
Memory |
|
2 x 184-pin DIMM sockets support two 2.5V DDR SDRAMs (DDR400/333/266) |
|
Maximum: 2GB |
|
|
|
Expansion Slots |
|
1 x AGP 8X |
|
3 x PCI Slot |
|
1 x CNR slot |
|
|
|
LAN |
|
VIA VT6103L 10/100Mbps Fast Ethernet PHY |
|
|
|
Audio |
|
Realtek ALC655 6-channel audio codec |
|
Compliant with AC97 2.3 specification |
|
|
|
IDE |
|
2 x UltraDMA 133/100/66 |
|
|
|
Back Panel I/O Ports |
|
1 x PS/2 keyboard |
|
1 x PS/2 mouse |
|
1 x Parallel Port |
|
1 x Serial Port |
|
1 x VGA port |
|
4 x USB 2.0 Ports |
|
1 x RJ 45 Port |
|
1 x Audio I/O (Line-in, Line-out and Mic-in) |
|
|
|
Internal I/O Connectors & Headers |
|
20-pin ATX power supply connector |
|
4-pin ATX 12V power supply connector |
|
2 x USB 2.0 header support additional 4 USB2.0 ports |
|
2 x Serial ATA connectors |
|
1 x Front panel switch/LED header |
|
1 x Front panel audio header |
|
CPU / SYS FAN headers |
|
1 x IrDA for SIR header |
|
1 x Speaker header |
|
1 x CD in header |
|
1 x Floppy connector-support 360K~2.88MB FDDs |
|
|
|
System BIOS |
|
AMI 4Mb Flash ROM |
|
Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI |
|
Full support for ACPI revision 1.0 specification |
|
|
|
Form Factor |
|
Micro-ATX Form Factor, 244220mm |
|
|
