| CPU |
LGA775 socket for Intel®Pentium D/Pentium 4/Celeron CPU
Support Intel® 65nm Pentium® D/ Intel® Pentium® 4/ Celeron® processors.
Compatible with Intel® 05B/05A and 04B/04A processors
Support Intel®EM64T/Hyper-Threading Technology |
| Chipset |
VIA PT880 Ultra
VIA VT8237A |
| Front Side Bus |
1066 / 800 / 533 MHz |
| Memory |
2 x 240-pin DIMM Sockets support max. 2GB DDR2 533/400 non-ECC, unbuffered memory
2 x 184-pin DIMM Sockets support max. 2GB DDR 400/333/266 non-ECC, unbuffered memory
(Note: DDR and DDR2 memory can not be used simultaneously) |
| Expansion Slots |
1 x AGP8X
1 x PCI-E X16 (max. X4 mode)
3 x PCI |
| Storage/RAID |
2 x UltraDMA 133/100
2 x Serial ATA with RAID0, 1, JBOD support |
| LAN |
Realtek RTL8201CL 10/100 LAN PHY |
| Audio |
ADI AD1986A High Definition Audio 6-channel CODEC
S/PDIF out on back I/O port |
| USB |
Max. 8 USB2.0/1.1 ports |
| Special Features |
CrashFree BIOS 2
ASUS EZ Flash
MyLogo |
| BIOS |
4 Mb Flash ROM,AMI BIOS, Green, PnP, DMI2.0, WfM2.0, ACPI2.0a, SM BIOS 2.3 |
| Back Panel I/O Ports |
1 x Parallel
1 x COM Port
1 x S/PDIF Out
1 x PS/2 Keyboard
1 x PS/2 Mouse
1 x RJ45
4 x USB 2.0/1.1
6-channel Audio I/O |
| Internal I/O Connectors |
2 x USB 2.0/1.1 connectors supports additional 4 USB 2.0/1.1 ports
CPU / Chassis / Power fan connectors
Front panel High Definition Audio connector
CD audio-in connector
24-pin EATX 12V Power connector
4-pin ATX +12V Power connector |
| Support Disc |
Drivers
ASUS PC Probe II
ASUS LiveUpdate Utility
Anti-virus software (OEM version) |
| Accessories |
1 x Serial ATA cable
1 x SATA power cable
1 x UltraDMA 133/100/66 cable
1 x FDD cable
1 x I/O Shield
Users manual |
| Form Factor |
ATX Form Factor, 12"x 8.6"(30.5cm x 22.9cm) |
.
